    Full Stainless Steel Filter Press For Sludge Dewatering Simple Structure

    Ask Lasest Price
    Brand Name : XinMing
    Model Number : XMY10/450/630/800
    Certification : CE, ISO9001, SGS
    Price : Negotiable
    Payment Terms : T/T, D/A, D/P, Western Union
    Supply Ability : 10000 sets per years
    Delivery Time : Within 25-35 days
    • Product Details
    • Company Profile

    Full Stainless Steel Filter Press For Sludge Dewatering Simple Structure

    Full Stainless Steel Long Live Automatic Pressure Maintaining Durable Press Machine​


    Product introduction


    Full Stainless Steel Filter Press For Sludge Dewatering Simple Structure


    The filter press USES the pressure difference between the two sides of the press cloth to force most of the water in the material to pass through the filter cloth and out of the body, and the material is blocked in the filter room to form a filter cake, so as to achieve the purpose of filtering. Due to the great pressure difference between the two sides of the press cloth during the filtration process, the filtration speed is improved and the water content of the filter cake is reduced. Moreover, the special press cloth is used to make the filtrate pure and clear, and the filtration effect is much better than that of the vacuum filter machine.


    Product advatage


    The feeding port is located in the middle of the filter plate, with large aperture, small resistance and uniform stress in all parts, which is suitable for all kinds of materials that are difficult to filter. It is particularly convenient for the user to design a three-piece jacket without press cloth locking device, and use direct suture to stitch the press cloth together, which is convenient, economical and durable.


    Full Stainless Steel Filter Press For Sludge Dewatering Simple Structure


    Full Stainless Steel Filter Press For Sludge Dewatering Simple Structure

    Full Stainless Steel Filter Press For Sludge Dewatering Simple StructureFull Stainless Steel Filter Press For Sludge Dewatering Simple StructureFull Stainless Steel Filter Press For Sludge Dewatering Simple Structure


    Technical Data


    ModelXA(M)Y12/450-30U
    Filter Area(m2)12
    Plate Size(mm)450*450
    Cake Thickness(mm)30
    Filter Chamber Volume(L)182
    Plate Qty(pcs)29
    Filtration Pressure(MPa)≥0.6
    Motor Power(Kw)2.2
    Weight(kg)1060
    Dimensions L*W*H(mm)2950*700*900
    Foundation Size L/B/D/H(mm)2450/300/700/650/450

    Feature


    1. Simplified structure

    2. No need power supply

    3. Solid&liquid separation

    4. Suitable for 12 m2 filtration area

    Application

    Fine chemical of industries,food, beverage,beer,sugaring...


    Full Stainless Steel Filter Press For Sludge Dewatering Simple Structure


    Chengdu Xinming Environmental Protection Co., Ltd is a professional equipment manufacturing enterprises , specialized in design ,manufacture and sales of various filtration equipment as well as comprehensive filtration solutions and projects. We have a sound quality assurance system and advanced testing equipment ,can be from raw material into the factory warehousing , processing , assembly , to the whole machine factory supervision and control throughout the process . we have the high-class R&D personnel , experienced workers and high qualified sales team , we are devoting to provide best products for our clients


    RFQ:


    Q1: What is the Warranty for the machines?

    A1: 12 months for free.


    Q2: When can I get the price?

    A2: Within 24 hours, if urgent, please directly call us.


    Q3: Whether the machine price can be more discount?

    A3: In general, our MOQ is 1set with very reasonable price, but if large order, we also can apply to our Manager to appropriately give you a little discount.


    Q4: How to ask quotation?

    A4: Please directly tell us which item you are interested in, or note us what tpye of materials, and how many tons of materials you want to treat per day or per hour, then we will send you quotation as soon as we can.


    Q5: How long will it take to receive my products?

    A5: As a general rule, it will take one 25-35 days for us to produce.
