Professional Automatic Stainless Steel 2 Micron Water Filter Press


Stainless Steel Filter Press:

1. Hydraulic compressing, automatic maintaining pressure

2. PLC control

3 .Feeding pressure 0.6 Mpa

4. Automatic shifting and discharging

5. Higher stabiliser

6. Stainless steel structure

7. Raw reinforced polypropylene filter plate

8. Protecting type shifter

9. ISO9001:2008 quality management system, ISO14001:2004 environmental management system and CE certified

10. Warranty period 1 year

Technology Parameters

Model	BAQ30/630
Filter Area(m2)	30
Plate Size(mm)	630*630
Cake Thickness(mm)	25
Filter Chamber Volume(L)	377
Plate Qty(pcs)	37
Frame Qty(pcs)	38
Filtration Pressure(MPa)	0.6
Weight(kg)	4130
Dimensions L*W*H(mm)	3280*950*1010

Outsourcing components

Item No.	Description	Manufacturer
1	Motor of hydraulic station	ABB
2	Major electric components	Schneider
3	PLC	Siemens
4	Hydraulic valve, Germany Rexroth Series	Beijing Huade
5	Filter cloth	Southwest filter cloth

Working principle

Suspension liquid is fed into sealed room by pump,under pressure,thefiltratethrough thefilterlayer and thefilter cloth, and dischargethroughthefilter clothexit mouth,residuesremain in thefilterbox,so as to achievethepurposeofsolid-liquid separation

Feature of stainless steel filter press

Between the filter frame and filter plate or filter by the cardboard seal is large than a filter , filter area of 2m2 or more stainless steel frame precision filter (also know as stainless steel plate filter ) the following configuration for placement of a fixed horizontal cardboard variety of health, wine, up to sterilization effect.

Applicable field

1) Chemical
Coating, paint, silica, caustic soda, soda ash, alkali, salt mud, new, water purification machines (aluminum, aluminum polymerization acetylacetonate, gypsum, insurance, phosphor, lithopone)
2)Foods
Vegetable oil, monosodium glutamate, glucose, starch sugar, plant sweet, maltose, starch, maize, rice, Joan, seaweed, kara glue, milk, oral liquid, beer yeast, soy sauce, rice wine, white wine, fruit juice, beverage, plant protein, and spices
3)Sewage
Printing and dyeing wastewater, sewage, smelting, leather, pharmacy sewage water brew, electroplating wastewater, sewage and waste, chemical electrolysis of water environment
4) Pharmacy
Strain, HuangLianSu, aureomycin and McGrady enzymes enzyme, Wells, inositol guangzhoumetro, phytic acid, calcium, Chinese traditional medicine, saccharification, growth hormone, organophosphate, pig’s blood
5) Pottery clay
Bentonite, electronic ceramic soil, kaolin, active soil, porcelain clay, limestone, granite furnaces
6) Metallurgy, coal
Gold, silver, copper, zinc ore mineral powder, etc
7) Petroleum
Diesel oil, sesame oil, shortening dewaxing etc
